End Caps

The End Caps are high-performance sealing components designed for safely closing and terminating pipeline systems in compressed air, vacuum, and inert gas applications. Engineered for reliability, durability, and easy installation, they ensure secure sealing performance in a wide range of industrial fluid transport systems.

Product Overview

The End Caps are designed to provide a stable and leak-proof closure for aluminum alloy piping systems. They are widely used in industrial pipelines where safe termination or temporary sealing of the system is required.

Suitable for compressed air, vacuum systems, and inert gases such as helium, nitrogen, and argon, these components ensure system integrity and operational safety under demanding conditions.

Key Features

Reliable sealing solution for pipeline end termination
Compatible with compressed air, vacuum, and inert gas systems
Stable working pressure up to 16 bar
Wide temperature resistance: -20°C to +80°C / -60°C to +180°C
Corrosion-resistant and long service life
Easy installation and maintenance-free design
Suitable for modular aluminum alloy piping systems

Material Construction

Sprayed aluminum alloy structure for lightweight strength
Stainless steel reinforcement for corrosion resistance
Engineering plastics for sealing stability and durability

These materials ensure excellent mechanical performance, corrosion resistance, and long-term operational reliability.

Product Parameters

End Cap Specifications

S.N	Nominal Diameter (mm)	W (mm)	H (mm)
11 0400 01	DN20 (Assembled)	48	54.7
22 0400 01	DN25 (Assembled)	53	54.7
11 0400 00	DN20	48	54.7
22 0400 00	DN25	53	54.7
44 0400 00	DN40	43.8	43.2
55 0400 00	DN50	53.8	43.2
66 0400 00	DN65	75.2	58.2
77 0400 00	DN80	92.4	58.2
88 0400 00	DN100	109.6	58.2
99 0400 00	DN125	132.6	70
CC 0400 00	DN148	155.6	75
BB 0400 00	DN200	212.6	75

Application Fields

The End Caps are widely used in:

Industrial compressed air pipeline systems
Vacuum piping networks
Inert gas distribution systems (nitrogen, argon, helium)
Aluminum alloy modular piping systems
Manufacturing and automation systems
Energy and industrial process pipelines

Company Introduction

Suzhou Jieyou Fluid Technology Co., Ltd., founded in August 2019, is a technology-driven enterprise specializing in the R&D, production, sales, and installation of advanced fluid transport systems.

The company’s main product lines include UPIPE aluminum alloy piping systems and Liq-pipe solutions, recognized for safety, corrosion resistance, environmental friendliness, and long-term stability.

With strong technical expertise and multiple patents, the company has obtained ISO 9001, ISO 14001, CE, and high-tech enterprise certifications. Its products are exported worldwide, serving customers across industrial, civil, and military sectors.

System Advantages

Safe and reliable pipeline sealing performance
Fast installation and easy system integration
Energy-efficient and stable operation
Strong anti-corrosion properties
Clean and environmentally friendly system design

Ten-Year Quality Assurance

UPIPE series products are covered by a 10-year quality guarantee, ensuring free replacement or repair after proper installation, testing, and acceptance.

Warranty Exclusions Include (but are not limited to):

Expired warranty period without valid extension agreement
Damage caused by improper installation or misuse
Operation outside specified environmental or technical conditions
Failure to follow installation or maintenance instructions
Corrosion, external impact, or incorrect handling
Unauthorized modification or system alteration

Summary

The End Caps provide a reliable and durable solution for sealing and terminating industrial pipeline systems. With high-quality materials, precise engineering, and excellent sealing performance, they ensure safe and long-lasting operation in compressed air, vacuum, and inert gas applications.
