MWD-610 Microwave Digestion System
Auto vent and self-resealing vessel ensures higher safety and less element loss.Contactless Temperature and Pressure Monitoring System.Compatible with 6/8/10/12-position sample rotor.
[Product Advantages]
1. Compatible with 6/8/10/12-position sample rotor.
2. Imported contactless IR sensor and pressure sensor, real-time display the
temperature and pressure of sample solution (NOT Vessel Wall) in each vessel and
show T&P scanning curve.
3. No consumables, e.g. bursting disk, sealing cup, etc. lower maintenance
cost.
4. Equip with smart 7 inches touch screen, user-friendly UI.
5. Pre-installed multiple international application methods. Users can also
edit, modify and delete the methods.
6. Equip with 316L stainless explosion-proof cavity, coated with multi-layer
anti-corrosive and heat resisting coatings, which greatly prolongs its service
life and ensure the safety of operation.
7. High power turbulent air cooling design makes fast cooling.
8. Professional electromagnetic protection design, compatible with high-level
microwave leakage protection standards.
[Technical Specification]
|
Model |
MWD-610-T6 |
MWD-610-T8 |
MWD-610-T10 |
MWD-610-T12 |
|
Vessel Quantity |
6 |
8 |
10 |
12 |
|
TemperatureMonitoring |
Contactless IR Sensor Temperature Monitoring Each Vessel Temperature Controlled Temperature Controlling Range: 50-400℃ Max. Working Temperature: 250℃ Temperature Accuracy: ±0.1℃ |
|||
|
PressureMonitoring |
Contactless Sensor Pressure monitoring Each Vessel Pressure Controlled Pressure Controlling Range: 0-15MPa Max. Working Pressure: 6Mpa Pressure Accuracy: ±0.01MPa |
|||
|
Vessel Volume |
100mL |
|||
|
Sample Vessel Material |
Imported TFM |
|||
|
Protection VesselMaterial |
PEEK+Glass Fiber |
|||
|
Display |
7 inches ColorTouch Screen |
|||
|
Rotation |
One Direction 360° continuous rotating |
|||
|
Microwave Cavity |
316L stainless steel cavitywith corrosion-proof coating |
|||
|
Microwave Power |
0-1000W (Adjustable) |
|||
|
Microwave Leakage |
<5mW/cm2 |
|||
|
Air Exhaust |
High power corrosion-proof air blower |
|||
|
Power |
AC 220V±10%, 10A, 50/60Hz |
|||
