A lane stacker is provided in the center of the berths on both sides, and the operation of the entire garage is completed by the stacker and the carrier. The stacker uses advanced technology to seamlessly integrate the lifting and walking systems, realizing the function of lifting while walking, saving time, reducing energy consumption, and maximizing space utilization.

There is an aisle stacker in the center of the parking spaces on both sides,
and the operation of the entire garage is completed by the stacker and the
transporter. When the car enters the garage, the car stops on the access
platform. The stacker takes the car from the access platform and walks and lifts
it in the aisle to transport the car to the designated layer of the parking
space. The transporter on the stacker sends the car from the stacker to the
parking space.

Equipment features:

1. There is no car loading plate on the parking space, only a steel plane,
which is efficient and relatively low in cost

2. The net height of the parking space layer only needs 1700mm

3. The handling method uses a manipulator holding type, which has the
characteristics of high system integration, fast handling speed, and low failure
rate

4. The ultra-thin manipulator independently developed by our company
(international invention patent) is used to realize the free storage and access
of cars with a chassis larger than 110mm.

5. Flexible layout, flexible setting of entrances and exits

6. Convenient and highly intelligent, optimized storage and access

7. Safe and intelligent

8. Green and environmentally friendly

9. Remote monitoring and real-time control

Handling mechanism

Manipulator
