Copper Material Y-Type Strainers
Zhejiang Wandong Valve Co., Ltd. is located in Oubei Town, Wenzhou City, known as the “hometown of pumps and valves in China”.
Applications:
Y-type strainers are essential pipeline devices designed to mechanically filter impurities (e.g., rust, sand, and solid particles) from liquids or gases, protecting downstream equipment from damage or clogging. Their Y-shaped configuration allows for easy installation in horizontal or vertical pipelines while maintaining low flow resistance.
Industrial Fluids: Water, steam, oils, acids, and non-corrosive gases (e.g., ammonia, oxygen).
Oil & Gas: Pipeline protection for pumps, compressors, and metering systems.
Chemical Processing: Filtering corrosive liquids in reactors or heat exchangers.
Power Plants: Pre-treatment for cooling water and boiler feed systems.
Main Features:
Dual-Purpose Structure:Removable Strainer Basket: Facilitates quick cleaning without pipeline disassembly.
Drain Plug: Enables debris flushing during operation.
Compact & Robust: Forged or cast body designs comply with ASME/API standards for high-pressure environments.
Design Features:
Body Structure: Bolted Bonnet, Y type.
Bore: Full Bore
Connection: RF Flange, BW, etc.
Product details:
Size: 2” ~ 48”
Pressure Rating: 150LB ~ 2500LB
Temperature: -196Deg. C ~ 600Deg. C
Material Available:
|
Carbon steel |
A216 Gr. WCB , WCC , WCA , etc |
|
Low temperature steel |
A352 Gr. LCB , LCC , LC1 , etc |
|
Alloy steel |
CN7M alloy 20 , CN3M alloy 20 modified , CT15C , etc |
|
Stainless Steel |
A351 Gr. CF8 , CF8M , CF3 , CF3M , CF8C , etc |
|
Aluminum bronze |
B148 C95500 , C95600 , C95800 , etc |
|
Monel |
M30C , M35-1 , CZ100 , etc |
|
Etc….. |
